ION-M4 Master unit
Configuration for 1 to 8 Smart OTRx with RMC1900 incl. BBU, AC - prepared for 1 Smart OTRx module
Order number:
7000 00758052
Manufacturer number: 7158775-7771
View accessories
View compatible articles
Product information
The product is an optical master unit of the Smart type.
The optical master unit can accommodate up to 8 fiber optic modules.
Equipment:
1x chassis (3 U) with 8-way splitter in the downlink (DL) and 8-way combiner in the uplink (UL) without fiber optic modules
2x Multiflex cables for the first fiber optic module
1x AC power supply
1x variable attenuator for 1x DL and 1x UL in one module
1x SAC address module
Accessories:
The following modules and accessories are available for equipping the optical master unit with fiber optic modules:
COM Smart OTRx 1/4 MU-G - Article no.: 7000 00757650
COM RF Multiflex cable - Article no.: 7000 00751675 - 2 cables are required for each Smart OTRx module
Extensions:
See sections assemblies and other accessories
