RFS 500 m RLKW 1/2" RADIAFLEX®, fire protection class B2ca s1a d0 a1
View accessories
RADIAFLEX® functions as a distributed antenna for communication in tunnels, mines and large building complexes and is the solution for any application in confined spaces.
Slots in the copper outer conductor allow a controlled proportion of the internal RF energy to be radiated into the environment. Conversely, a signal transmitted near the cable is coupled into the slots and transmitted over the entire length of the cable.
RADIAFLEX® is used for both one-way and two-way communication systems, and due to its broadband capability, a single radiating cable can handle multiple communication systems simultaneously.
This RADIAFLEX® radiating cable uses a low-loss cellular polyethylene foam dielectric and a smooth copper outer conductor that provides excellent electrical performance along with good bending characteristics.
FEATURES/ADVANTAGES
- Broadband from 30 MHz to 980 MHz
- For applications in tunnels and buildings
- Low variations in coupling losses
| Article image | Article number | Manufacturer number | Description | Manufacturer |
|---|---|---|---|---|
|
7000 00599100 | 43F-RA12-P02 |
RFS Premium 4.3-10 coupler for RADIAFLEX® 1/2" cable
|
Radio Frequency Systems GmbH |
|
7000 00621900 | NF-RA12-012 |
RFS N coupler for RADIAFLEX® 1/2" cable
|
Radio Frequency Systems GmbH |
|
7000 00622200 | NM-RA12-011 |
RFS N connector for RADIAFLEX® 1/2" cable
|
Radio Frequency Systems GmbH |
| Article image | Article number | Manufacturer number | Description | Manufacturer |
|---|---|---|---|---|
|
7000 00668600 | TRIM-SET-R12-P02 |
RFS Universal trimming tool for RADIAFLEX® 1/2" for mounting connector types -P02
|
Radio Frequency Systems GmbH |
