RFS 300 m RLK 7/8" RADIAFLEX® Fire protection class Dca s1b d2 a1

RADIAFLEX® functions as a tubular antenna for communication in tunnels, mines and large building complexes and is the solution for any application in confined spaces.
Slots in the copper outer conductor allow a controlled proportion of the internal RF energy to be radiated into the environment. Conversely, a signal transmitted near the cable is coupled into the slots and carried along the length of the cable.

RADIAFLEX® is used for both one-way and two-way communication systems. Due to its broadband capability, a single radiating cable can handle multiple communication systems simultaneously.

This RADIAFLEX® radiating cable uses a low-loss cellular polyethylene foam dielectric with a smooth copper outer conductor that provides excellent electrical performance, along with good bending characteristics.

FEATURES / ADVANTAGES


• Broadband from 30 MHz to 980 MHz
• For applications in tunnels and buildings
• Low variations in coupling losses
