PRO DPF 70/4-9/13 BNC, 4-circuit duplex filter, frequency range 406-470 MHz, BNC coupler - Please specify frequency

Order number: 7000 00513900

Manufacturer number: 200000306

Product information

The DPF 70/4... is a 4-cavity duplex filter for duplex radio telephones.
The DPF 70/4.... can be set within the entire 406 - 470 MHz band. The duplexer can be supplied in four different versions depending on the desired duplex spacing.
The DPF 70/4... is primarily intended for devices where TX and RX are operated on individual frequencies, but can also be used, albeit with slightly reduced data, where TX and RX operate on several channels, i.e. within a certain port bandwidth. In the latter case, factory tuning is recommended.
The filter uses ¼ full length cavities in a compact, extruded aluminum housing. The housing is made of passivated steel, and Teflon insulation has been used in the coaxial cable and connectors.
The filter is coated with black vinyl to prevent corrosion.

Data sheet 7000 00513900 (EN)
