PBE OMU squelch interface in 2U 19’ housing, 380-386.5 MHz/390-396.5 MHz, power supply 48 VDC
Order number:
7000 00753976
Manufacturer number: 60-307502
View compatible articles
Product information
The installation of this product enables additional noise suppression (also known as squelch or uplink muting) between an optical distribution system and a base station.
Please pay attention to the frequency range to be ordered.
This is an active suppression of noise in large distribution systems, such as campus solutions or metropolitan concepts.
- Nominal gain of 0dB, can therefore also be used in existing systems
- Noise suppression option for uplink and/or downlink
- Central noise suppression at the RF handover point to the base station
- Channel-selective mode
- Timeslot-based muting in channel-selective mode
- Easy setting of gain and noise suppression threshold via webGUI
- Compact design for cabinet mounting
- Ethernet LAN interface for local operation
- Alarm contact for integration into local fault reporting system
- 4 potential-free alarm inputs for monitoring additional devices
Additional technical information regarding typical group runtimes (delay):
- Channel-selective TETRA mode 90kHz filter: 11us
- Channel-selective TETRA mode 60kHz filter: 14us
