PBE BSF 2502 Optical remote unit, 2m BOS, 167.5-169.5/172.0-174.0 MHz, power supply 48 VDC, 5U, 19" housing, double fibre optic cable

Order number: 7000 00752343
Manufacturer number: 60-307201
View accessories
Product information



VHF band-selective fiber optically connected repeater for BOS in the 2m band



FEATURES/ADVANTAGES



The BSF 2502 RM-2F-D is a fiber optically powered VHF repeater. The repeater is part of a system that is fed by a PBE Axell Optical Master Unit (OMU). The OMU couples the RF signals from a nearby base station and modulates the RF signals into optical signals that are distributed via fiber optic cable to one or more remote BSF repeaters. The maximum allowable optical loss is 10 dBo between the OMU and the furthest last remote unit supporting the OMU.



  • These remote BSF repeaters can be installed up to 20 km from the base station site and offer great flexibility in providing RF coverage in areas where off-air reception is not a desirable or possible solution.
  • The remote BSF repeaters demodulate the optical signal into RF and feed it into a Distributed Antenna System (DAS) or radiating cable to distribute the RF signal throughout the area to be covered.
  • The high output power of the remote BSF repeaters means that fewer decentralized units need to be deployed, which reduces the investment costs for deployment.



request Product
Data sheet 7000 00752343 (EN)
