RFS Grounding kit, Premium, for LCF158 cable with 0.6 m 6AWG cable
Order number:
7000 00625800
Manufacturer number: GKSPEED20-158P
View accessories
View compatible articles
Product information
This grounding kit was developed by RFS for the CELLFLEX® cable series. The housing of the grounding kit facilitates proper attachment to the coaxial cable and ensures that the performance of the coaxial cable is not compromised. The tinned copper braid provides a secure, low impedance contact to the outside of the cable. Conductor. Installation only takes a few minutes. No additional sealing with mastic and electrical tape required.
FEATURES/ADVANTAGES
- Compatible with copper and aluminum cable types, i.e. one grounding kit for both outer conductor materials eliminates the risk of incorrect installation of the grounding kit and helps to keep stock levels low.
- This kit has been tested by independent laboratories to withstand the damaging effects of a lightning current in excess of 100kA 10/350µs in accordance with EN 50164. The copper wire provides the most practical and effective low inductance transmission of lightning induced current to earth.
- No effect on the electrical transmission characteristics of the coaxial cable.
- Rugged mechanical construction.
- UV-resistant in accordance with DIN EN ISO 4892-2 (Plastics - Methods of exposure to laboratory light sources - Part 2 Xenon arc lamps).
- Ozone-resistant in accordance with DIN 53509 (Testing of rubber - Determination of resistance to ozone cracking).
- RoHS-compliant (EU 2002/95/EC) and CRoHS-compliant (China SJ/T11363-2006), i.e. can be used worldwide.
Article image | Article number | Manufacturer number | Description | Manufacturer |
---|---|---|---|---|
7000 00662200 | JSTRIP-158-2 |
RFS Stripping tool for LCF158
|
Radio Frequency Systems GmbH |
Article image | Article number | Manufacturer number | Description | Manufacturer |
---|---|---|---|---|
7000 00757842 | LCF158-50JA-1-500 |
RFS 500 m 1 5/8" standard coaxial cable
|
Radio Frequency Systems GmbH | |
7000 00757843 | LCF158-50JFNA-1-500 |
RFS 500m 1 5/8" coaxial cable, standard, fire protection class Cca s1a d2 a1
|
Radio Frequency Systems GmbH | |
7000 00757844 | LCF158-50CPR-1-500 |
RFS 500m 1 5/8" coaxial cable, standard, fire protection class B2ca s1a d0 a1
|
Radio Frequency Systems GmbH | |
7000 00753198 | LCF158-50JFNA-Cd2 |
RFS 1 5/8" coaxial cable, flame-retardant, fire protection class Cca s1a d2 a1
|
Radio Frequency Systems GmbH | |
7000 00753199 | LCF158-50JFNA-Cd0 |
RFS 1 5/8" coaxial cable, flame-retardant, fire protection class Cca s1a d2 a1
|
Radio Frequency Systems GmbH |
