RFS 500 m RLK 1/2" RADIAFLEX® Fire protection class Cca s1a d1 a1

Order number: 7000 00750831

Manufacturer number: RLK12-50JFNA

Product information

RADIAFLEX® acts as a distributed antenna for communication in tunnels, mines and large building complexes and is the solution for any application in confined areas.

Slots in the copper outer conductor allow a controlled portion of the internal RF energy to be radiated into the environment. Conversely, a signal transmitted near the cable is coupled into the slots and propagated along the entire length of the cable.

RADIAFLEX® is used for both one-way and two-way communication systems, and because of its broadband capability, a single radiating cable can serve multiple communication systems simultaneously.

This RADIAFLEX® radiating cable uses a low-loss cellular polyethylene foam dielectric and a smooth copper outer conductor that provides excellent electrical performance along with good bending characteristics.

FEATURES / ADVANTAGES

Broadband from 30 MHz to 980 MHz
For applications in tunnels and buildings
Low variation in coupling losses

request Product

Data sheet 7000 00750831 (EN)
