FIM 50x 7/8" 1-part RAW-APP clamp, 80 mm spacing, for cable tray 7x1.25, Ø 26.5-28 mm
Order number:
7000 00148500
Manufacturer number: 61 5045 0078
View compatible articles
Product information
FEATURES/ADVANTAGES
RAW - APP - One-piece clamps for radiating cables
- The RAW - APP cable clamps have been specially developed for the quick installation of radiating cables on cable trays/channels or on cable ladders, provided with rectangular slots in 7x35mm, 9x35mm and 11x35mm.
- The RAW - APP cable clamps can be securely installed on metal conductors with a thickness of 1.25 - 1.5 mm and with an integrated spacer of 80 mm.
- The RAW - APP cable clamps are used for quick installation of radiating cables on cable trays/channels or on cable ladders without the need for tools.
- For installation, insert the base of the cable clamp into the rectangular slot of the cable tray/channel and turn it to the locking position.
- To ensure a fire-protected installation, a clamp should be installed every 5-10 m as RAW + RSD with corresponding screw connection.
FI.MO.TEC. S.p.A.
Via Belvedere 11
20861 Brugherio
Italy
https://www.fimoworld.com/de/kontakte/
https://www.fimoworld.com
Via Belvedere 11
20861 Brugherio
Italy
https://www.fimoworld.com/de/kontakte/
https://www.fimoworld.com
| Article image | Article number | Manufacturer number | Description | Manufacturer |
|---|---|---|---|---|
|
7000 00753889 | 85150850_500M |
H+S SUCORAD_7/8_LM_FR, 500m radiating 7/8’ cable on drum Size: 124x78cm, fire protection class Eca
|
HUBER+SUHNER GmbH |
|
7000 00754285 | 85150850_300M |
H+S SUCORAD_7/8_LM_FR, 300 m radiating 7/8’ cable on A1290 drum, fire protection class Eca
|
HUBER+SUHNER GmbH |
